Specification

StyleReturn Filter
MediaWire Mesh
Efficiency 150µ
Outer Diameter 124.5 mm
Inner Diameter 96.5 mm
Length 921.0 mm
Bypass Pressure 3.0 BAR bar
Δ Collapse Pressure 20 bar
Seal MaterialNitrile
Temperature Range -30 - +100°C

Description

The FF201928B is our FilterFinder Approved replacement to the Stauff RE600B40B4. Our element is designed to meet or exceed the quality and performance of the original Stauff filter, ensuring superior filtration performance and long-lasting durability.



Engineered with our wire mesh media and a durable design, the FF201928B provides reliable and consistent performance over its lifespan, even in harsh operating environments. With FilterFinder, you can trust that you are getting a reliable and high-quality replacement filter that will keep your system running smoothly.

Stauff Brand Logo

Stauff Product

Genuine Stauff RE-600-B-50-B/2

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
50µ
Efficiency 2
Style Return Filter
Outer Diameter 124.5 mm
Inner Diameter 96.5 mm
Length 921.0 mm
Media Type Wire Mesh
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

3.0 BAR
Collapse Pressure 20 BAR
Seal Nitrile
Temperature Range -30 - +100°C
